Wholesale round supply air diffuser supplier

Company Advantages
1. The production of Ventech adopts automation technology. The raw materials have been optimally utilized due to computerized production, control, and inspection. This product can withstand extreme temperature variations
2. Strong strength of Ventech ensures the quality of the entire company. This product is perfectly suitable for damp areas such as toilets and bathrooms
3. The product is durable enough. It does not easily wear over time and does not demand frequent maintenance and elements replacement. This product can be easily fixed and removed
4. The product features position precision. It is designed with automatic control function which can achieve high precision positioning control and self-adaptation control. It has been certified under CE for safe operation





LINEAR SLOT DIFFUSER



VENTECH Linear Slot Diffusers are an attractive alternative to the ceiling or high sidewall supply diffusers. Slot diffusers can be installed individually in set lengths or in a continuous line. They can also be installed in any type of ceiling application.



The modules are available with a 20mm or 25mm Slot with the number of slots ranging from 1 to 6 slots and are further available as fixed or removable core. (Fixed Core - Model LSD-VA, Removable Core – LSD-VB.)



The air pattern control is adjustable from the diffuser face and is achieved by means of an adjustable pattern control with each slot, enabling a full 90º air pattern adjustment. The suggested volume control should be from the main duct run take-off, or from a butterfly damper fitted to the inlet of the cushion head box.

Features:

• ·Concealed screw fixing

  ·Finish: off white standard, other colors on demand

  ·Made from high grade extruded aluminum profiles & sheets.

  ·Accessories: Hit & miss damper, plenum box-top/side entry connection

Details:

• Surface Finish: Powder coated color finish as per RAL color----standard color: RAL9016, 9010.
• Material thickness: 1.2mm
• Accessory: Adaptor Optional





Drawing- with Adaptor











Company Features
1. The factory is located in a zone with abundant manpower resources. This enables us to exploit the advantage of talent backwardness to reduce the cost of innovation.
2. We never stop searching for sustainable growth. We support more sustainable production patterns by reducing the environmental impact of our products.
