High quality supply air diffuser factory

Company Advantages
1. In the selection of raw materials, Ventech is paid 100% attention. Our quality team adopts the highest standard for the selection of raw materials and thus ensures the high quality of the product.
2. The product is applicable in the industry due to its promising development prospects. It has been certified under CE for safe operation
3. The light transmittance of this kind of product can be up to a very high level, and its material can effectively eliminate the reflection from all directions. This product is capable of providing excellent air distribution
4. This product is not prone to voltage problem. It is has been carefully designed to accommodate voltages in different countries. This product is available in various kinds of powder coating





LINEAR SLOT DIFFUSER



VENTECH Linear Slot Diffusers are an attractive alternative to the ceiling or high sidewall supply diffusers. Slot diffusers can be installed individually in set lengths or in a continuous line. They can also be installed in any type of ceiling application.



The modules are available with a 20mm or 25mm Slot with the number of slots ranging from 1 to 6 slots and are further available as fixed or removable core. (Fixed Core - Model LSD-VA, Removable Core – LSD-VB.)



The air pattern control is adjustable from the diffuser face and is achieved by means of an adjustable pattern control with each slot, enabling a full 90º air pattern adjustment. The suggested volume control should be from the main duct run take-off, or from a butterfly damper fitted to the inlet of the cushion head box.

Features:

• ·Concealed screw fixing

  ·Finish: off white standard, other colors on demand

  ·Made from high grade extruded aluminum profiles & sheets.

  ·Accessories: Hit & miss damper, plenum box-top/side entry connection

Details:

• Surface Finish: Powder coated color finish as per RAL color----standard color: RAL9016, 9010.
• Material thickness: 1.2mm
• Accessory: Adaptor Optional





Drawing- with Adaptor











Company Features
1. The factory has established rigorous quality management systems and production standards. These systems and standards require the QC team to strictly control & inspect product quality throughout all stages.
2. We are committed to more sustainable development. We have worked toward energy efficiency, waste reduction, and other ecological measures.
