Model | FP200KM4 | FP300KM4 | FP400KM4 | FP500KM4 | FP600KM4 | FP800KM4 | |||
Air volume | Q | H | m3/h | 360 | 510 | 680 | 850 | 1020 | 1360 |
M | 250 | 420 | 560 | 650 | 780 | 1050 | |||
L | 200 | 350 | 460 | 520 | 600 | 800 | |||
Z | H | m3/h | 340 | 510 | 680 | 850 | 1020 | 1360 | |
M | 280 | 390 | 520 | 650 | 785 | 1030 | |||
L | 230 | 300 | 400 | 500 | 605 | 860 | |||
Cooling capacity | Q | H | W | 2000 | 2710 | 3620 | 4530 | 5440 | 7200 |
M | 1700 | 2410 | 3100 | 3830 | 4485 | 6000 | |||
L | 1500 | 2140 | 2750 | 3360 | 3500 | 4500 | |||
Z | H | W | 1750 | 2620 | 3500 | 4370 | 5400 | 7000 | |
M | 1410 | 2250 | 2920 | 3645 | 4440 | 5890 | |||
L | 1020 | 1860 | 2430 | 3040 | 3745 | 4900 | |||
Heating capacity | Q | H | W | 3000 | 4070 | 5440 | 6800 | 8160 | 10800 |
M | 2810 | 3520 | 4650 | 5750 | 6700 | 9350 | |||
L | 2480 | 3150 | 4130 | 5100 | 5200 | 7690 | |||
Z | H | W | 2770 | 4130 | 5250 | 6750 | 8100 | 10500 | |
M | 1990 | 3010 | 4370 | 5460 | 6450 | 8750 | |||
L | 1310 | 2530 | 3645 | 4370 | 5190 | 7290 | |||
Noise level | Q | ≤dB(A) | ≤dB(A) | 37 | 39 | 41 | 43 | 45 | 46 |
Z | ≤dB(A) | ≤dB(A) | 37 | 39 | 41 | 43 | 45 | 46 |
